140ATI03000 Schneider Brandy Original Factory Sealed New

Name: 140ATI03000 Schneider Brandy Original Factory Sealed New
SKU: 140ATI03000
Price: 889.86 USD
Availability: InStock

US$ 889.86

添加收藏

添加到購物車

估算運費

成功添加到購物車

140ATI03000 Schneider Brandy Original Factory Sealed New

color:red,size:xxl

合計: US$ 0

查看我的購物車

結帳

詳情

商品名稱: 140ATI03000 Schneider Brandy Original Factory Sealed New
產品型號: 140ATI03000
重量: 0.8 kg = 1.7637 lb = 28.2192 oz
分類: Schneider_Original New_In Stock
標簽: Schneider PLC , Modicon , 140ATI03000
創建日期: 2019-04-25

TC input, 8 channels, type J, K, E, T, S, R, B
140ATI03000 Schneider Analog input module Modicon Quantum - 8 I thermocouple
Brand: Schneider Electric
Condition: Schneider Original Factory New Sealed
Warranty: 13 Months
Delivery Time: Send out within 3-6 working days
Shipment: DHL free shipping

Main
range of product	Modicon Quantum automation platform
product or component type	Analogue input module
type of filter	Notch filter - 3 dB at 50/60 Hz Single pole low pass - 3 dB at 20 Hz

Complementary
analogue input number	8
addressing requirement	10 input words
analogue input type	Thermocouple - 210...760 °C thermocouple J Thermocouple - 270...1000 °C thermocouple E Thermocouple - 270...1370 °C thermocouple K Thermocouple - 270...400 °C thermocouple T Thermocouple - 50...1665 °C thermocouple R Thermocouple - 50...1665 °C thermocouple S
analogue input resolution	16 bits
input impedance	> 1 MOhm
absolute accuracy error	+/- 2 °C plus + 0.1 % of reading thermocouple J +/- 2 °C plus + 0.1 % of reading thermocouple K +/- 2 °C plus + 0.1 % of reading thermocouple T +/- 4 °C plus + 0.1 % of reading thermocouple R +/- 4 °C plus + 0.1 % of reading thermocouple S +/- 2 °C plus + 0.1 % of reading thermocouple E
linearity error	1 °C, 0.1 °C, 1 F, 0.1 F - 210...760 °C 1 °C, 0.1 °C, 1 F, 0.1 F - 270...1000 °C 1 °C, 0.1 °C, 1 F, 0.1 F - 270...1370 °C 1 °C, 0.1 °C, 1 F, 0.1 F - 270...400 °C 1 °C, 0.1 °C, 1 F, 0.1 F - 50...1665 °C
accuracy drift according to temperature	0.15 µV/°C + 0.0015 % of reading/°C max low level voltage
common mode rejection	> - 120 dB 50/60 Hz
isolation between channels and bus	1780 V AC for 60 s 2500 V DC for 60 s
isolation between channels	220 V AC 300 V DC
update time	1000 ms
fault type	Broken wire Overtacking scale
marking	CE
cold junction compensation	Internal 32...140 °F (0...60 °C)
local signalling	1 LED green bus communication is present (Active) 1 LED red external fault 8 LEDs green channel is turned on 8 LEDs red channel fault
bus current requirement	280 mA
power dissipation in W	1.5 W
module format	Standard
product weight	0.66 lb(US) (0.3 kg)

Environment
standards	CSA C22.2 No 142 UL 508
product certifications	CUL FM Class 1 Division 2
resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields	9.14 V/yd (10 V/m) 80...1000 MHz conforming to IEC 801-3
ambient air temperature for operation	32...140 °F (0...60 °C)
ambient air temperature for storage	-40...185 °F (-40...85 °C)
relative humidity	95 % without condensation
operating altitude	<= 16404.2 ft (5000 m)
